  • New ProSense DPM3-E-A2R-L Digital Panel Meter 22-53V AC/10.5-70V DC, 2-SPDT, 1/8 DIN
New ProSense DPM3-E-A2R-L Digital Panel Meter 22-53V AC/10.5-70V DC, 2-SPDT, 1/8 DIN
$200.00 USD
Shipping calculated at checkout.
Warranty Terms and Conditions
We have 1 in stock!

Not finding what you need?‎ ‎ Let us find it!

Next Day Automation is NOT an authorized distributor for Automation Direct. The Original Manufacturer's warranty may not apply. This is a surplus item.

Product Description

Item Condition: New
SKU: SB-173170
PQ-3-A

From our inventory we are selling a Automation Direct DPM3-E-A2R-L Digital AC/DC Panel Meter Current/Volts 1/8 DIN.

Specifications:

  • Model #: DPM3-E-A2R-L
  • More Information:
    • Digital AC/DC Panel Meter
      • Type: Current/Volts
      • Size: 1/8 DIN
      • Display: 14mm, 5 Digits, Tri-Color (Red, Green, Amber) LED
      • Input Current Signal Range:
        • 0-200mA AC True RMS
        • 0-1A AC True RMS
        • 0-5A AC True RMS
        • shunt 0-50mV AC True RMS
        • shunt 0-60mV AC True RMS
        • shunt 0-100mV AC True RMS
        • +/- 200mA DC
        • +/- 1A DC
        • +/- 5A DC
        • shunt +/- 50 mVDC
        • shunt +/- 60 mVDC
        • shunt +/- 100 mVDC
      • Input Voltage Signal Range:
        • 0-2VAC True RMS
        • 0-20VAC True RMS
        • 0-200VAC True RMS
        • 0-600VAC True RMS
        • +/- 2VDC
        • +/- 20VDC
        • +/- 200VDC
        • +/- 600VDC
      • Output: 4-20mA, 2x 8A SPDT Relays
      • Power Requirements: 22-53VAC, 10.5-70VDC
